TYPE AS
TYPE ASB
EPAC Type AS and Type
ASB - Stirrup Clamps are designed for tapping energized cables without
arcing damage to the conductor.
FEATURES
A stainless steel
spring clip provides a snap action on installation, prevents arcing and
holds the stirrup in position on the conductor.
The clamp body
and cap are of high strength, heat treated aluminum alloy and recommended
for use on ACSR or aluminum conductor in a wide range of sizes.
Tin plated copper loops are bonded into clamp bodies.
Galvanized
steel bolts are retained to prevent turning and sufficient length for
installing without removing nuts.
Type ASB -Bent
Bail - The 45°
angle of the copper bail provides easier access for installation.
|
CATALOGUE |
CABLE
RANGE |
DIMENSIONS
IN INCHES |
AMPACITY |
|||||||
|
NUMBER |
MIN. |
|
MAX. |
A |
B |
C |
D |
E |
F |
|
|
AS-2/0-556XB |
2/0 |
- |
556
ACSR |
4 |
5
1/4 |
5 |
#2/0 |
2
1/2 |
1/2 |
400 |
|
|
(.447 |
- |
.927) |
|
|
|
|
|
|
|
|
ASB-6-4/0 |
#6 |
- |
4/0
ACSR |
3 |
2
5/8 |
3
9/16 |
#1/0 |
2 |
3/8 |
200 |
|
|
(.198 |
- |
.563) |
|
|
|
|
|
|
|
